    12 Core Single Mode Fiber Optic Cable GYXTW GYXTY Steel Tape Armored For Outdoor

    Ask Lasest Price
    Brand Name : ZXOFC
    Model Number : ZXOFC-GYXTW/GYXTY
    Certification : CE,ISO9001,ROSH
    Price : Negotiable
    Payment Terms : T/T, Western Union,Paypal,Credit card
    Supply Ability : 10000KM per month
    Delivery Time : 1-2 weeks according to the lengths
    • Product Details
    • Company Profile

    12 Core Single Mode Fiber Optic Cable GYXTW GYXTY Steel Tape Armored For Outdoor

    Optical Fiber Cable GYXTW GYXTY 12 Core Single Mode Fiber Optic Cable For Outdoor Use


    Description

    GYXTW Armored Uni-Tube Single Jacket/Single Armored cable is designed with the flexibility and versatility


    required for today's most demanding installations, including direct buried. The metallic armor is used when


    mechanical protection is desired.


    Product Construction:

    Fiber:

    2-24 fiber

    Uni-loose tube gel-filled


    Strength Member:

    Steel Wire


    Armor:

    Corrugated steel tape


    Outer Jacket:

    Black UV Polyethylene(PE)


    Features:

    • Uni-tube gel-filled construction for superior fiber protection.
    • Metallic armor to protect cable from rodent attack and mechanical damage.
    • Embedded steel wire provide desirable tensile strength and crush resistance.
    • Compact, easy to install.
    • UV and waterproof design.

    Application:

    • Interbuilding voice or data communication.
    • Installed in duct, underground conduit.
    • FTTx.

    Structure and Technical Specifications


    Fiber

    Count

    Nominal

    Diameter

    (mm)

    Nominal

    Weight

    (kg/km)

    Allowable Tensile Load

    (N)

    Allowable Crush Resistance
    (N/100mm)
    Short TermLong TermShort TermLong Term
    2~128.69515006001000300
    14~249.011015006001000300

    Note : This datasheet can only be a reference, but not a supplement to the contract. Please contact our sales people for

    more detailed information.


    We produce and test cable comply with following standard:

    Mechanical Performance
    Max Tension PerformanceIEC 60794–1-2-E
    Max. Operation TensionIEC 60794–1-2-E1
    Crush TestIEC 6079 –1-2-E3
    Impact TestIEC 60794–1-2-E4
    Repeated BendingIEC 60794–1-2-E6
    Torsion TestIEC 60794–1-2-E7
    Cable bendIEC 60794–1-2-E11A
    Attenuation CoefficientITU-T G.652
    Structural TestIEC-60793-1-20
    Environmental Performance
    Temperature CyclingIEC 60794–1-2-F1
    Water PenetrationIEC 60794–1–2-F5B
    Filing Compound FlowIEC 60794-1-E14
