    ODLC To LC CPRI Fiber Optic Cable For FTTA Antenna Station

    Ask Lasest Price
    Brand Name : ZXOFC
    Model Number : PDLC-LC
    Certification : CE ISO9001
    Price : Negotiable
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 10000 KM per month
    Delivery Time : 5-10 working days
    • Product Details
    • Company Profile

    ODLC To LC CPRI Fiber Optic Cable For FTTA Antenna Station

    CPRI Fiber Optic Outdoor Cable ODLC To LC Patch Cord Jumper For FTTA Attenena Station


    Description


    FTTA outdoor CPRI SC/LC/FC/ST fiber patch cable


    CPRI fiber patch cable for the new generation wireless base stations (WCDMA/TD-SCDMA/WiMax/GSM). Such products can be meet the


    FTTA(fiber to the top of the tower) program requirements for outdoor environment conditions and adverse weather conditions. Especially in the


    3G, 4G, and WiMax base stations and fiber-optic distributed zoom technology, CPRI fiber patch cable are rapidly becoming the standard


    connector interface.


    Feature

    Open bulkhead for easy access to SFP

    Positive mechanical feedback to operator when fully mated

    One-hand mating

    Plug has tolerance free design, fully free floating on Z-axis

    No Cable buckling during or after installation

    Cost effective metal die cast bulkhead

    Field installable version available

    Water proof, dust proof and corrosion resistant

    Good mechanical and environmental characteristics;

    Flame retardant characteristics meet the requirements of relevant standards;

    The mechanical characteristics of jacket meet the requirements of relevant standards;

    Soft, flexible, water blocked, UV resistant, easy to lay and splice, and with big capacity data transmission;

    Meet various requirements of market and clients

    Bulkhead cutout allows for removal of transceiver through the bulkhead (no need to open PRH for transceiver replacement)

    Robust bayonet locking for easy, fast, and secure mating


    Technique paremeter


    Item
    Singlemode
    Multimode
    Outer diameter
    5.0mm
    5.0mm
    Standard color
    black
    black
    Cable weight
    35kg/km approx
    Operating temperature
    -40℃~+85℃
    Storage temperature
    -40℃~+85℃
    Tensile strength
    Short term
    1000N
    Long term
    600N
    Compression resistant strength
    ≥3000N/100MM
    General attenuation
    1310nm
    ≤0.4dB/km
    850nm
    ≤3.0dB/km
    1550nm
    ≤0.3dB/km
    1300nm
    ≤1.0dB/km
    Minimal Bending radius
    ≥30D
    ≥30D
    Printing contents
    OPTICAL CABLE SM(G657A) 5.0mm DUPLEX TPU XXXXM
    OPTICAL CABLE MM(62.5/125) 5.0mm DUPLEX TPU XXXXM
