6 Core Military Armored Tactical Fiber Field Tactical Cable
Connector Optic Jumper Cable
Description
SpecificationsPrice-Competitive
Low Insertion Loss & PDL
Factory-terminated and Tested
With the continuous development of optical fiber communication
technology, 3G commercial trial network, high-speed local area
networks and optical access network such as the market that is a
sustained manner. Especially in the 3G, 4G, and WiMax base stations
and fiber-optic distributed zoom technology, ODLC fiber optic cable
connector assemblies are rapidly becoming the standard connector
interface.
ODLC fiber optic connectors for the new generation wireless base
stations pulled far (WCDMA/TD-SCDMA/WiMax/GSM) tailored products
that can be meet the FTTA(fiber to the top of the tower) program requirements for outdoor environment conditions and adverse weather conditions.
Patch Cord Features
* IP65 protection, salt-mist proof
* Easy, reliable and cost-effective installation
* The connector of side-A is duplex LC, and side-B can be LC, SC or
FC
* Thread structure guarantees the trusted connection
Technique Parameters
| Item | Specifications |
| Connector | LC/UPC-LC/UPC |
| Fiber amount | 6 cores |
| Fiber type | Single mode 9/125um 652DG.657A1 |
| Optical Cable Attenuation at 1310nm | 0.4dB/km |
| Optical Cable Attenuation at 1550nm | 0.3dB/km |
| IL/Connector | ≤0.3dB IEC 61300-3-4 |
| Return Loss/Connector | >50dB IEC 61300-3-6 |
| Operation Temperature Range | -20-70℃ |
| Storage Temperature Range | -20-85℃ |
| Tensile strength | 350 N maximum |
| Bending radius | 180nm minimum |
| Crush Resistance | 1500 N/100 mm |
| Outer sheath | TUP,PE, full cable armored |
| Cable sheath color | Black |
| Cable OD5.5 | 5.0mm +/-0.2mm |
