    FRP GYFTA53 Non Metallic Fiber Optic Cable Double Armor Sheath G652D

    Ask Lasest Price
    Brand Name : ZX-OFC
    Model Number : GYFTA53
    Certification : CE/RoHS
    Price : $0.1-$2.5
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 100 kilometers per days
    Delivery Time : 7-15 days
    • Product Details
    • Company Profile

    FRP GYFTA53 Non Metallic Fiber Optic Cable Double Armor Sheath G652D


    The GYFTA53 cable is constructed by inserting a 250μm fiber into a loose tube made of a high-modulus material filled with a water-repellent compound. The center of the core is a non-metallic reinforcing core (FRP). For some cores, a non-metallic reinforcing core is required to be extruded with a layer of polyethylene (PE). The loose tube (and the filling rope) is twisted around the central reinforcing core into a compact and round core, and the gap in the core is filled with a water blocking filler. The plastic coated aluminum strip (APL) is longitudinally wrapped and then extruded with a polyethylene inner sheath. The double-sided coated steel strip (PSP) is longitudinally wrapped and extruded into a polyethylene outer sheath to form a cable.

    Standards

    The GYFTA53 fiber optic cable complies with YD/T 901 and IEC 60794-1 standards.

    Features

    • Has good mechanical properties and temperature characteristics • The loose tube material itself has good hydrolysis resistance and high strength • The tube is filled with a special grease to protect the fiber • Good pressure resistance and softness • The following measures are taken to ensure the waterproof performance of the cable: - Single non-metallic center reinforcement core - The loose tube is filled with special waterproof compound - Full core filling - Plastic coated aluminum tape (APL) moisture barrier - Double-sided coated steel strip (PSP) improves the moisture resistance of the cable - Good water blocking material prevents longitudinal leakage of cable.
    Q1. What is your terms of packing?
    A: Generally, we pack our goods in drum with pallet for import.Every 2KM/3KM/4KM/5KM for one drum.And the dimension of the drum can be customized according to your requirement.
    Q2. What is your terms of payment?
    A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
    Q3. What is your terms of delivery?
    A: EXW, FOB, CFR, CIF, DDU.
    Q4. How about your delivery time?
    A:Generally, it will take 10 to 20 days after receiving your prepayment. The specific delivery time depends on the items and the quantity of your order.
    Q5. Can you produce according to the samples?
    A: Yes, we can produce by your samples or technical drawings.
    Q6. What is your sample policy?
    A: We can provide FREE sample if we have them in stock, but the customers have to pay the courier cost.
    Q7. Do you test all your goods before delivery?
    A: Yes, we have 100% test before delivery
    Q8: How do you make our business long-term and good relationship?
    A:We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.And we keep good quality and competitive price to ensure our customers benefit .
